| Lens |
f=4.0 mm
F 1.8
Board lens
Dual-band
Fixed
IR corrected
|
| Field of View |
71° (horizontal)
52° (vertical)
90° (diagonal)
|
| Shutter Time |
1/5 ~ 1/15,000 sec
|
| Image sensor |
1/4" CMOS in 640 x 480 Resolution
|
| Minimum Illumination |
0.001 Lux @ F1.8 ( typical )
|
| IR Illuminators |
IR LED*12
Built-in IR illuminators, Effective up to 10 meter
|
| Video |
Compression: H.264, MPEG-4 & MJPEG
Streaming:
Simultaneous dual streams
H.264 streaming over UDP, TCP, HTTP or HTTPS
H.264/MPEG-4 multicast streaming
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MJPEG streaming over HTTP or HTTPS
Supports 3GPP mobile surveillance
Frame rates:
H.264: Up to 30/25 fps at 640x480
MPEG-4: Up to 30/25 fps at 640x480
MJPEG: Up to 30/25 fps at 640x480
|
| Image Settings |
Adjustable image size, quality, and bit rate
Time stamp and text caption overlay
Flip & mirror
Configurable brightness, contrast, saturation, sharpness, white balance and exposure control
AGC AWB AES
Automatic, manual or scheduled day/night mode
Supports privacy masks
|
| Networking |
10/100 Mbps Ethernet, RJ-45
ONVIF support
Protocols: IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X
|
| Alarm and Event Management |
Triple-window video motion detection
1 D/I for external sensor and alarm
Event notification using HTTP, SMTP, FTP
Local recording of MP4 files
Tamper Detection
|
| Security |
Multi-level user access with password protection
IP address filtering
HTTPS encrypted data transmission
802.1X port-based authentication for network protection
|
| Users |
10 clients on-line monitoring at the same time
|
| Dimensions |
Width: 150mm
Ø: 60mmCable length: 400 mm
Cable diameter: Ø 12 mm; Max Connector: Ø 18 mm
|
| LED Indicator |
System restore status indicator
|
| Power |
12V DC
24V AC
Power consumption: Max. 4 W
802.3af Power-over-Ethernet (Class 2)
|
| Housing |
Weather-proof IP66-rated housing
|
| Approvals |
CE C-Tick FCC LVD VCCI
|
| Operating Environments |
Temperature: -20 ~ 50 °C (-4 ~ 122 °F )
Humidity: 90%
|
| Viewing System Requirements |
OS: Microsoft Windows 7 / Vista / XP / 2000
Browser: Mozilla Firefox
Browser: Internet Explorer 7.x or above
VLC:10.5 or above
QuickTime:6.5 or above
Cell phone: 3GPP player
Real Player 10.5 or above
|
| Installation Management and Maintenance |
Installation Wizard 2
32-CH Central management software
Supports firmware upgrade
|
| Applications |
SDK available for application development and system integration
|
| Warranty |
24 Months
|
