| Lens |
f=2.9 ~ 8.2 mm
F 1.0
auto iris
CS-mount
Vari-focal
Removable IR-cut filter for day & night function
|
| Field of View |
26.7° ~ 69.0° (horizontal)
20.0° ~ 51.0° (vertical)
|
| Shutter Time |
1/30 ~ 1/15,000 sec
|
| Image sensor |
1/4" SONY progressive scan CCD in VGA Resolution
|
| Minimum Illumination |
0.2 Lux / F1.0 ( typical )
|
| Video |
Compression: MJPEG & MPEG-4
Streaming:
Simultaneous multiple streams
MPEG-4 streaming over UDP, TCP, HTTP or HTTPS
MPEG-4 multicast streaming
MJPEG streaming over HTTP or HTTPS
Supports 3GPP mobile surveillance
Frame rates:
MPEG-4: Up to 30/25 fps at 640x480
MJPEG: Up to 30/25 fps at 640x480
|
| Image Settings |
Adjustable image size, quality, and bit rate
Time stamp and text caption overlay
Flip & mirror
Configurable brightness, contrast, saturation, sharpness, white balance and exposure control
AGC AWB AES
Automatic, manual or scheduled day/night mode
Supports privacy masks
BLC (Backlight compensation)
|
| Audio |
Compression
GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps
Interface:
Built-in microphone
External microphone input
Audio output
Supports two-way audio
Supports audio mute
|
| Networking |
10/100 Mbps Ethernet, RJ-45
Built-in 802.11 b/g WLAN
Protocols: IPv4, TCP/IP, HTTP, UPnP, RTSP/RTP/RTCP, SMTP, FTP, DHCP, NTP, DNS, DDNS
|
| Alarm and Event Management |
Triple-window video motion detection
1 D/I & 1 D/O for external sensor and alarm
Event notification using HTTP, SMTP, FTP
Local recording of MP4 files
|
| Security |
Multi-level user access with password protection
IP address filtering
Wireless: WEP, WPA-PSK, WPA2
|
| Users |
10 clients on-line monitoring at the same time
|
| Dimensions |
Depth: 205.5mm
Width: 82.1mm
Height: 51.2mm
|
| Weight |
Net: 581 g
|
| LED Indicator |
System power and status indicator
System activity and network link indicator
|
| Power |
12V DC
24V AC
Power consumption: Max. 4 W
|
| Approvals |
CE C-Tick FCC LVD VCCI
|
| Operating Environments |
Temperature: 0 ~ 50 °C (32 ~ 122 °F)
Humidity: 20% ~ 80%
|
| Viewing System Requirements |
OS: Microsoft Windows 2000 / XP / Vista
Browser: Mozilla Firefox
Browser: Internet Explorer 7.x or above
VLC:10.5 or above
QuickTime:6.5 or above
Cell phone: 3GPP player
Real Player 10.5 or above
|
| Installation Management and Maintenance |
Installation Wizard 2
32-CH Central management software
Supports firmware upgrade
|
| Applications |
SDK available for application development and system integration
|
| Warranty |
24 Months
|
