CPU	Multimedia SoC (System-on-Chip)
Flash	128 MB
RAM	256 MB

Image sensor	1/3.2" CMOS
Maximum Resolution	1600x1200
Lens Type	Vari-focal
Focal Length	f = 3 ~ 9
Aperture	1.2 ( wide ), 2.1 ( tele )
	DC-iris
Field of View	29.95° ~ 83.34° (horizontal) 22.99° ~ 61.93° (vertical) 39.87° ~ 104.52° (diagonal)
Shutter Time	1/5 sec. to 1/40,000 sec.
Day & Night	Removable IR-cut filter for day & night function
Minimum Illumination	0.1 Lux @ F1.2, 50 IRE 0.001 Lux @ F1.2, 50 IRE ( B/W )
Pan / Tilt / Zoom	ePTZ 16x digital zoom ( 4x on IE plug-in ,4x built-in )
IR Illuminators	Built-in IR illuminators, Effective up to 25 meter IR LED * 24
On-board Storage	SD/SDHC/SDXC card slot

	H.264, MJPEG & MPEG-4
Maximum Frame Rate	H.264: Up to 30 fps at 1280x720, Up to 15 fps at 1600x1200 MPEG-4: Up to 30 fps at 1280x720, Up to 15 fps at 1600x1200 MJPEG: Up to 30 fps at 1280x720, Up to 15 fps at 1600x1200
Maximum Streams	4 simultaneous streams
S/N Ratio	Above 42.3 dB
Dynamic Range	Above 69.4 dB
Video Streaming	Configurable video cropping for bandwidth saving
Image Settings	Adjustable image size, quality, and bit rate Time stamp and text caption overlay Configurable brightness, contrast, saturation, sharpness, white balance and exposure control BLC (Backlight compensation) Supports privacy masks Scheduled profile settings

Audio Capability	Audio input / Audio output ( )
	GSM-AMR AAC G.711
	External microphone input External line output

Users	Live viewing for up to10 clients
	IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X
Protocols	10 Base-T / 100BaseTX Ethernet (RJ-45)
ONVIF	Ver. 1.02

Video Motion Detection

Triple-window video motion detection

Alarm Triggers	Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection
Alarm Events	Event notification using digital output, HTTP, SMTP, FTP and NAS server File upload via HTTP, SMTP, FTP and NAS server

Connectors	RJ-45 cable connector for Network/PoE connection Audio input Audio output DC 12V 24V AC Power input Digital input * 1 Digital output * 2 RS-485 SD/SDHC/SDXC card slot
LED Indicator	System restore status indicator
Power input	12V DC 24V AC 802.3af Power-over-Ethernet (Class 3)
Power consumption	Max. 5.82 W (DC 12V ) Max. 8.1 W (AC 24V ) Max. 7.2 W (PoE )
	Ø: 83 mm x 212.5 mm
Weight	Net: 1600 g
Casing	Weather-proof IP67-rated housing
Safety Certifications	CE C-Tick FCC ( Class A ) LVD VCCI
Operating Temperature	Operating Temperature: -20 ~ 50 °C (-4 ~ 122 °F ) Starting temperature: -20 °C ( -4°F )
Warranty	24 Months

Operating System	Microsoft Windows 2000 / XP / Vista
Browser	Mozilla Firefox 7~10 ( Streaming only ) Internet Explorer 7.x or 8.x
Other Players	VLC:1.1.11 or above QuickTime:7 or above
