CPU	Multimedia SoC (System-on-Chip)
Flash	128 MB
RAM	256 MB

Image sensor	1/2.5" Progressive CMOS
Maximum Resolution	2560x1920
Lens Type	Vari-focal, CS Mount
Focal Length	f = 2.8 ~ 12 mm
Aperture	F1.2 (wide) ~ F2.5 (tele)
	DC-iris
Field of View	28.2° ~ 115.3° (horizontal) 21.3° ~ 84.2° (vertical) 35.5° ~ 150.2° (diagonal)
WDR Technology	WDR Enhanced
Day & Night	Removable IR-cut filter for day & night function
Minimum Illumination	0.02 Lux @ F1.2 (Color) 0.001 Lux @ F1.2 (B/W)
Pan / Tilt / Zoom	ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)
On-board Storage	SD/SDHC/SDXC card slot

	H.264, MJPEG & MPEG-4
Maximum Frame Rate	H.264: 10 fps at 2560x1920 30 fps at 1920x1080 MPEG-4: 10 fps at 1920x1536 25 fps at 1920x1080 MJPEG: 13 fps at 2560x1920 30 fps at 1920x1080
Maximum Streams	3 simultaneous streams
S/N Ratio	Above 60 dB
Dynamic Range	57 dB
Video Streaming	Adjustable resolution, quality and bitrate Configurable video cropping for bandwidth saving
Image Settings	Adjustable image size, quality and bit rate Time stamp, text overlay, flip & mirror Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks Scheduled profile settings

Audio Capability	Audio input/output (full duplex)
	GSM-AMR, AAC, G.711
	Built-in microphone External microphone input External line output
Effective Range	5 meters

Users	Live viewing for up to 10 clients
	IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X
ONVIF	Ver. 1.02

Video Motion Detection

Triple-window video motion detection

Alarm Triggers	Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection
Alarm Events	Event notification using digital output, HTTP, SMTP, FTP and NAS server File upload via HTTP, SMTP, FTP and NAS server

Smart Focus System	Focus assist button and OSD
Connectors	RJ-45 cable connector for Network/PoE connection Audio input Audio output Video output AC 24V power input DC 12V power input Digital input*1 Digital output*1
LED Indicator	System power and status indicator
Power input	24V AC 12V DC IEEE 802.3af PoE Class 3
Power consumption	Max. 4.87 W (DC 12V) Max. 7 W (AC 24V) Max. 6.8 W (PoE)
	218 mm (D) x 72 mm (W) x 62 mm (H)
Weight	Net: 702 g
Safety Certifications	CE, LVD, FCC Class A, VCCI, C-Tick
Operating Temperature	Starting Temperature: 0°C ~ 50°C (32°F ~ 122°F) Working Temperature: -10°C ~ 50°C (14°F ~ 122°F)
Warranty	24 months

Operating System	Microsoft Windows 7/Vista/XP/2000
Browser	Mozilla Firefox 7~10 (Streaming only) Internet Explorer 7.x or 8.x
Other Players	VLC: 1.1.11 or above Quicktime: 7 or above
